right side, certain amount below deck lid, certain distance from tailight.
No Lamborghini tail logo.
right side, reasonable position for early prototype
right side, reasonable position on an early prototype.
Note- period photos do support a special case for Miura logo position to the right as shown for prototypes.
right side Miura script is correct position.
Lamborghini logo to left in correct position, but not correct to be on this early Miura.
right side Miura script is correct position.
notice backup light peeking from behind grille in center.
of course missing all the correct license light hardware.
unrestored car, both logos correct position and use.
unrestored car, both logos correct position and use.
Both scripts in correct positions, the S looks a little vertical and upside down, so when flipped may come to look as it should.
looks very nice, correct scripts, but all scripts in the wrong locations.
license plate and lights moved to an SV position.
license now covers backup light.
correct scripts in correct locations.
license correct, license lights correct
correct scripts in the correct positions.
S in upsidedown position.
license moved and now the license covers the backup light.
looks very nice, correct scripts, but all scripts in the wrong locations.
S in upsidedown position
license plate and lights moved to an SV position.
license now covers backup light.
unrestored car appears with correct positions.
backup lights are part of tail light assembly.
looks very nice, but all scripts in the wrong locations.
S script incorrect.
I would like verification from other resources.
I need the pattern for the S model S logo
I need the pattern for the SV basic holes
I need the pattern for the SV model S logo
I need the pattern for the SV model V logo
